Description
Product Overview
The Blue Sea Systems 5005 ANL fuse block is engineered to provide dependable over‑current protection for a wide range of marine and off‑grid electrical applications. Constructed from high‑impact plastic, the housing resists corrosion and mechanical stress while the insulated cover complies with ABYC and USCG requirements, ensuring safety in harsh environments. The block features a swing‑out design that allows technicians to replace a blown fuse without the need to remove mounting fasteners, dramatically reducing service time and downtime. With a current rating of up to 300 A and a voltage rating of 32 V DC, this fuse block can handle substantial loads typical of trolling motor circuits, battery banks, and auxiliary equipment. The product dimensions of 4.5 inches wide by 1.65 inches high and a centerline length of 8 inches make it a compact yet powerful solution for panel‑mount installations. UL 94‑V0 rated material provides excellent heat resistance, and the stainless‑steel studs offer superior torque resistance for a secure electrical connection.
Usage
Designed for both professional installers and DIY enthusiasts, this fuse block excels in a variety of settings. On recreational vessels, it safeguards critical systems such as navigation lights, communication equipment, and high‑draw devices like winches and pumps. In remote off‑grid cabins, the block protects solar charge controllers, inverter circuits, and battery management systems from overloads. The ability to accept 5/16″ (M8) ring terminals provides flexibility for wiring configurations, allowing users to route cables in any direction through the cover breakouts. The insulated cover not only meets safety standards but also protects the fuse contacts from accidental short circuits during maintenance. Whether mounted on a dedicated electrical panel or integrated into a custom enclosure, the 5005 model delivers reliable performance in environments where reliability and ease of service are paramount.
Why Choose Us
Blue Sea Systems has a long‑standing reputation for producing marine‑grade electrical components that combine durability with user‑friendly design. The 5005 ANL fuse block reflects this heritage through its robust construction, corrosion‑resistant materials, and thoughtful engineering that prioritizes quick serviceability. Each unit undergoes rigorous testing to meet UL standards, ensuring that it can withstand the high temperatures and vibration typical of marine applications. The limited warranty offered by the manufacturer provides additional peace of mind, guaranteeing that the product will perform as advertised for the duration of its service life. Moreover, the company’s extensive support network and technical resources empower customers to install and troubleshoot the fuse block with confidence.
Key Features
- Swing‑out design enables fuse replacement without removing mounting hardware, saving time during maintenance.
- High‑temperature resistant plastic housing (UL 94‑V0) ensures durability in extreme conditions.
- Insulated cover meets ABYC/USCG standards, providing added safety for users and equipment.
- Stainless‑steel studs deliver corrosion resistance and secure, high‑torque electrical connections.
- Comprehensive customer support and limited warranty give confidence in long‑term reliability.
FAQ
What size ring terminals does the fuse block accept?
The block is designed to accept 5/16″ (M8) ring terminals, allowing flexible wiring options for a variety of marine and off‑grid applications.
Can the fuse block be used for systems higher than 32 V DC?
No. The product is rated for a maximum of 32 V DC, and using it beyond this voltage could compromise safety and performance.
Is the fuse sold with the block?
No, the fuse is sold separately. This allows users to select the exact amperage rating needed for their specific circuit requirements.
How does the swing‑out design improve serviceability?
The swing‑out mechanism lets you access the fuse compartment without removing the mounting screws, which means you can replace a blown fuse quickly and with minimal disruption to the surrounding wiring.
What warranty does Blue Sea Systems provide for this product?
The fuse block comes with a limited warranty that covers manufacturing defects, giving customers assurance of quality and durability over the product’s lifespan.
