Description
Product Overview
The DC Power Fuse Distribution Strip Module is engineered for demanding DC power distribution tasks. Featuring a robust FR‑4 fiberglass dual‑copper PCB, the module delivers exceptional electrical performance and thermal stability. Its high‑quality fire‑proof nylon DIN‑rail carrier, sourced from reputable Taiwanese manufacturers, provides a secure 35 mm rail fit and resists deformation under load. The module supports a working voltage range of 0 to 32 V DC and can handle a maximum total input current of 30 A, making it suitable for a wide variety of applications from industrial control panels to automotive power systems.
Each of the six channels is equipped with a factory‑installed 3 A ATO/ATC fuse, which can be easily replaced with higher‑rated fuses up to 10 A, allowing users to tailor the current capacity to specific load requirements. The fuse holders feature a clear fail‑indication LED that illuminates when a fuse is blown or removed, providing immediate visual feedback and enhancing system safety. Input terminals are spaced at a 7.62 mm (0.3″) pitch, accommodating wire sizes from 26 to 10 AWG, while output terminals use a 5.0 mm (0.197″) pitch for 26 to 12 AWG wires. Both input and output connections employ metric slotted screws (M3 for inputs, M2.5 for outputs) for secure and repeatable terminations.
Usage
This module excels in environments where reliable DC power distribution is critical. In industrial automation, it can be mounted on standard DIN rails within control cabinets to feed sensors, actuators, and low‑voltage motor drives. Its compact 6‑position layout saves valuable panel space while providing clear organization of circuits. For automotive enthusiasts, the module offers a tidy solution for managing auxiliary lighting, infotainment systems, and battery management units, all while maintaining a high safety standard thanks to the built‑in fuse monitoring.
DIY hobbyists and makers will appreciate the ease of installation: the screw‑mount and DIN‑rail options allow flexible mounting configurations, and the straightforward fuse replacement process means quick adjustments during prototyping. The module’s robust construction ensures it can withstand the vibrations and temperature variations typical of mobile and outdoor applications, making it a versatile choice for a broad range of projects.
Why Choose Us
Choosing the CZH‑LABS DC Power Fuse Distribution Strip Module means selecting a product built on a foundation of quality and reliability. Our commitment to using premium materials—such as fire‑proof nylon carriers and FR‑4 PCB substrates—ensures long‑term durability and compliance with industry safety standards. Each unit undergoes rigorous testing for voltage tolerance, current handling, and thermal performance, guaranteeing consistent operation even under heavy load conditions.
We stand behind our products with responsive customer support and a clear warranty policy. Should you encounter any issues, our technical team is ready to provide guidance on installation, fuse selection, and troubleshooting. Additionally, the modular design allows seamless expansion: multiple modules can be linked together to create larger distribution systems without compromising performance.
Our focus on user‑friendly features, such as the LED fail‑indication and easy‑access fuse holders, reduces downtime and simplifies maintenance. By integrating this module into your power distribution architecture, you benefit from a streamlined, safe, and scalable solution that meets the demands of both professional engineers and passionate makers.
Key Features
- Compact 6‑position DIN‑rail design saves panel space while delivering reliable DC distribution.
- Replaceable 3 A ATO/ATC fuses with upgrade path to 10 A for flexible current handling.
- LED fail‑indication provides instant visual alert for blown or missing fuses, enhancing safety.
- Robust FR‑4 PCB and fire‑proof nylon carrier ensure durability in harsh industrial and automotive environments.
- Dedicated customer support and warranty for peace of mind and easy troubleshooting.
FAQ
What voltage range does the module support?
The module operates safely from 0 V up to 32 V DC, covering most low‑voltage applications.
Can I replace the factory‑installed 3 A fuses with higher‑rated fuses?
Yes, the fuse holders accept standard ATO/ATC fuses up to 10 A, allowing you to increase current capacity as needed.
How does the fail‑indication LED work?
The LED lights up when a fuse is blown or removed, providing an immediate visual cue that the circuit needs attention.
Is the module compatible with both screw‑mount and DIN‑rail installations?
Absolutely. The module is offered in both screw‑mount and DIN‑rail versions, giving you flexibility in mounting options.
What wire sizes can I use for the input and output terminals?
Input terminals accept 26‑10 AWG wires, while output terminals support 26‑12 AWG wires, accommodating a wide range of conductor gauges.
